D H6 H7 H8 H9 H10 H11 H12 e9 f7 f8 f9 h8 h9 h10 h11
0 < D ≤ 3 +0.006 -0 +0.01 -0 +0.014 -0 +0.025 -0 +0.04 -0 +0.06 -0 +0.1 -0 -0.014 -0.039 -0.006 -0.016 -0.006 -0.02 -0.006 -0.031 +0 -0.014 +0 -0.025 +0 -0.04 +0 -0.06
3 < D ≤ 6 +0.008 -0 +0.012 -0 +0.018 -0 +0.03 -0 +0.048 -0 +0.075 -0 +0.12 -0 -0.02 -0.05 -0.01 -0.022 -0.01 -0.028 -0.01 -0.04 +0 -0.018 +0 -0.03 +0 -0.048 +0 -0.075
6 < D ≤ 10 +0.009 -0 +0.015 -0 +0.022 -0 +0.036 -0 +0.058 -0 +0.09 -0 +0.15 -0 -0.025 -0.061 -0.013 -0.028 -0.013 -0.035 -0.013 -0.049 +0 -0.022 +0 -0.036 +0 -0.058 +0 -0.09
10 < D ≤ 18 +0.011 -0 +0.018 -0 +0.027 -0 +0.043 -0 +0.07 -0 +0.11 -0 +0.18 -0 -0.032 -0.075 -0.016 -0.034 -0.016 -0.043 -0.016 -0.059 +0 -0.027 +0 -0.043 +0 -0.07 +0 -0.11
18 < D ≤ 30 +0.013 -0 +0.021 -0 +0.033 -0 +0.052 -0 +0.084 -0 0.13 + 0 0.21 + 0 -0.04 -0.092 -0.02 -0.041 -0.02 -0.053 -0.02 -0.072 +0 -0.033 +0 -0.052 +0 -0.084 +0 -0.13
30 < D ≤ 50 +0.016 -0 +0.025 -0 +0.039 -0 +0.062 -0 +0.1 -0 +0.16 -0 0.25 + 0 -0.05 -0.112 -0.025 -0.05 -0.025 -0.064 -0.025 -0.087 +0 -0.039 +0 -0.062 +0 -0.1 +0 -0.16
50 < D ≤ 80 0.019 + 0 0.03 + 0 0.046 + 0 0.074 + 0 0.12 + 0 0.19 + 0 +0.3 +0 -0.06 -0.134 -0.03 -0.06 -0.03 -0.076 -0.03 -0.104 +0 -0.046 +0 -0.074 +0 -0.12 +0 -0.19
80 < D ≤ 120 +0.022 -0 +0.035 -0 +0.054 -0 +0.087 -0 +0.14 -0 0.22 + 0 0.35 + 0 -0.072 -0.159 -0.036 -0.071 -0.036 -0.09 -0.036 -0.123 +0 -0.054 +0 -0.087 +0 -0.14 +0 -0.22
120 < D ≤ 180 +0.025 -0 +0.04 -0 +0.063 -0 +0.1 -0 +0.16 -0 +0.25 -0 0.4 + 0 -0.085 -0.185 -0.043 -0.083 -0.043 -0.106 -0.043 -0.143 +0 -0.063 +0 -0.1 +0 -0.16 +0 -0.25
180 < D ≤ 250 +0.029 -0 +0.046 -0 +0.072 -0 +0.115 -0 +0.185 -0 0.29 - 0 +0.46 -0 -0.1 -0.215 -0.05 -0.096 -0.05 -0.122 -0.05 -0.165 +0 -0.072 +0 -0.115 +0 -0.185 +0 -0.29
250 < D ≤ 315 +0.032 -0 +0.052 -0 +0.081 -0 +0.13 -0 0.21 - 0 +0.32 -0 +0.52 -0 -0.11 -0.24 -0.056 -0.108 -0.056 -0.137 -0.056 -0.185 +0 -0.081 +0 -0.13 +0 -0.21 +0 -0.32
315 < D ≤ 400 +0.036 -0 +0.057 -0 +0.089 -0 +0.14 -0 +0.23 -0 +0.36 -0 +0.57 -0 -0.125 -0.265 -0.062 -0.119 -0.062 -0.151 -0.062 -0.202 +0 -0.089 +0 -0.14 +0 -0.23 +0 -0.36
400 < D ≤ 500 +0.04 -0 +0.063 -0 +0.097 -0 +0.155 -0 +0.25 -0 +0.4 -0 +0.63 -0 -0.135 -0.29 -0.068 -0.131 -0.068 -0.165 -0.068 -0.223 +0 -0.097 +0 -0.155 +0 -0.25 +0 -0.4
